Automatic Industrial Online Variable Date Qr Code Barcode Code Inkjet Printer Laser Marking Machine Inkjet Coding Printer UV Ink Jet Printing

Functional characteristics: System:Industrial Android SystemScreen:10.1 inch color screen,HD touch screen,What you see i

Send your inquiry

DESCRIPTION

Basic Info

Model NO.	WQ-UV-W3000
Working Patterns	On-Line
Supplies	Ink
Packaging	All
Customize	OEM
Specification	630450300mm
Trademark	Idjet /WEIQIAN LASER
Origin	China
HS Code	8443322100
Production Capacity	3500PCS/Year

Product Description

Automatic Industrial Online Variable Date Qr Code Barcode Code Inkjet Printer Laser Marking Machine Inkjet Coding Printer UV Ink Jet Printing

Functional characteristics: System:Industrial Android SystemScreen:10.1 inch color screen,HD touch screen,What you see is what you getNozzle:Imports of industrial Piezoelectric nozzle,Support multi-head and splicing expansionInk supply:Ink capsule precision negative pressure controlData:Online variable data printingDetect:Ink remaining detection, ink filling does not affect the print bodyVolume:Small size, wide adaptability, support for separation and customizationPrinting:Print down and Side printing

1.Parameters

Product model	Inkjet Coding Machine ---W3000
Nozzle parameters	Nozzle type: all imported industrial piezoelectric nozzles Maximum printing width: 32.4mm Number of nozzles: 384 Nozzle row spacing: 0.931mm Nozzle spacing: about 0.1693mm/column Nozzle row number: double row Ink drop: 3~21Pl variable ink drop
Display screen	Size :10.1 inch
Touch screen	Capacitive touch screen
Hardware interface	USB2.0 interface RS232 interface Curing light interface Encoder interface Flip-flop interface
Defend degree	IP54
Working environment	Working temperature: 0 ºC-45 ºC (best 10 ºC to 32 ºC) Humidity:15%-75% Protection requirements: good grounding
Size	Structure: stainless steel housing Power supply: AC220V/50HZ System power consumption: maximum power consumption 120W Equipment weight: about 25kg Machine size: 630450300mm Nozzle size: 4050120mm
Technical specification	Nozzle life: 30 billion times of ink ejection Printing distance: 3mm-5mm Printing content length: 1.8m Printing speed: 0-100m/min (ink volume 1) (decided by factors such as material/resolution/environment/platform) Longitudinal accuracy of nozzle: 300DPI Horizontal accuracy of print head: 300DPI-1200DPI Movement method: from left to right Printing direction: adjustable forward, reverse, vertical downward; adjustable up and down in the program, flip left and right Curing type: LED-UV curing
Features	Font library support: built-in a variety of commonly used font libraries, in addition to support font import function, users can import their own fonts.Input method: support Pinyin input method, handwriting input method, etc.Secondary development: the software provides interfaces to support secondary developmentMaterial type: flat materials such as aluminum plate, ceramic tile, glass, wood, metal sheet, acrylic plate, plastic, leather, bags, cartons and etc.Applicable products: such as mobile phone displays, beverage bottle caps, food packaging bags, medicine boxes, plastic steel doors and windows, aluminum alloys,Gold, batteries, plastic pipes, steel plates, circuit boards, chips, woven bags, eggs, brake pads, mobile phone shell cartons, motors, transformers, water meter inner plates, gypsum boards, PCB circuit boards, outer packaging, etc. Printing content: The system supports printing one-dimensional bar codes, two-dimensional bar codes, drug supervision codes, traceability codes, databases,Variable text, picture, logo, date, time, batch number, class and serial number, etc. And can be smart lively design the layout, content, and printing position.

Automatic Industrial Online Variable Date Qr Code Barcode Code Inkjet Printer Laser Marking Machine Inkjet Coding Printer UV Ink Jet Printing

Transport and Packing process

By Sea and Air delivery is available .

Express (UPS,DHL,Fedex,EMS,etc) is available .

Delivery Time

Samples: 7 working days .

100PCS or More orders: 25 working days .
