DESCRIPTION

Basic Info

Model NO.	S20
Working Patterns	On-Line
Supplies	Ink
Packaging	Bubble
Transport Package	Wooden Case
Specification	2500*3000*1500
Trademark	SCORER
Origin	China
HS Code	8443321300
Production Capacity	1500set/Year

Product Description

SCORER S20A/B inkjet system adopt Japanese industrial-grade piezoelectric industrial print head and the single print head width can reaches 54MM. The maximum speed can matching 180 min/m basis on different resolution ratio. Modular design facilitates installation and it is easy to use. Users only need to pass a short training to operate.Unique design CNC ink supply system, and equipped with independent control software.The volume is only 150MM cubic meters.It is the smallest independent ink supply system in the industry, real-time detection, dynamic control of ink temperature, positive pressure, negative pressure.Make sure that every drop of ink can land accurately.The equipment can be flexibly embedded on the production lines of different customer factories.Packaging a variety of sheet printing press, roll wheel printing press, roll wheel paper cutting machine, folding machine paste machine, box machine and so on.It can be widely used in one object,one code label, plastic soft bags, carton shipping marks, medical equipment, building materials, food packaging, drug packaging,ect.

Product features

1. High Speed Printing

Maximum speed at 180 meters per minute for UV Inkjet system,220 meters per minute for Water-based Inkjet system.
2.Modular Design

Easy maintenance . The weight of the whole set of equipment is only 10kg and the volume is 0.6m', which is easy to maintain.

3.Intelligent and low-consumed

It can keep on spraying on the line trimming print position and print the resolution. It is equipped with automatic cleaning function with less than 2kw energy consumption.

Product Parameters

Technical Specifications

Technical Specifications
Model	S20 A	S20B
Print Technology	Piezoelectric Drop On Demand
High Besolution	600dpi X 600dpi(with 8 different printing resolutions)prung
Print Width	54mml(modular compact design allows multiple printheads to be stitched together to form a w der printhead)
Print Contents	Alphanumeric text, Barcode, 2D code, Chinese/English Character, Static/Dynamic Bitmap
Highest Printing Speed	180 meters per minute	220 meters per minute
Drop size	6,7,11,17 pl	5,7,12,18 pl
Inkjet Printing Medium	Offset, Coated Paper, Carbon-less, Bond Paper, film, PVC and PETetc	Offset, Coated Paper, Carbon-less, Bond Paper etc
Ink Type	Imported environmental friendly UV ink	Imported environmental friendly water based ink
Drying Device	UVdrying system	Without drying
Operating Environment	Temperature 18-28ºC, humidity 50%-80% RH non-condensing
Power Requirement	220VAC 50-60HZ

Detailed Photos

Application

It can be used in anti-counterfeit labels, plastic soft bag, cardboard boxes,tin cans, clothing washing superscript/tag, medicine/food packaging.

Print Head

The S20 inkjet ystem adopts the (Ricoh) gray-scale piezoelectric print head with a width of 54MM and a service life of up to 10 billion printing times.Print ink drop size, minimum ink drop 6PL. Max 35PL.All steel nozzle is not easy to block and corrosion.Automatic piston type positive pressure cleaning, cleaning is not easy to damage.The printing scoring rate can reach 600DPI, with UV and water-based equipment for different materials, which can meet the needs of different customers for different materials.

Software

The S20 Inkjet system software has powerful functionality and flexible applications.Efficient and streamlined variable data printing workflow, can be imported into a variety of format data documents such as TXT.CSV.TFB.. Users can achieve accurate variable data, one-dimensional code QR code printing, PDF picture printing.You can also directly implant the date, time and other content.The dynamic adjustment of the printing position function reduces the position offset caused by the speed fluctuation of the external connection line when printing. Its greatly saves time and improves efficiency.We has the independent intellectual property rights of the software, supports the second development, and can be customized according to customer requirement. The spray printing of digital variable stealth code opens a new chapter in the field of anti-counterfeiting traceability.

Ink

SCORER S20 inkjet system adapted to UV and water based inks.UV ink is made of high quality UV ink with fast drying, friction resistance and scratch resistance, which has good printing adaptability, good curing speed and good adhesion.UV ink does not contain volatile organic compounds, do not need to add solvent, in the use of stable temperature, making the ink road smooth, not blocked, reduce waste, improve production efficiency. SCORER is very values ink safety, and providing MSDS reports and regular SGS testing. Zero pollution, environmental protection products.Save ink and improve efficiency.Water-based ink is more environmentally friendly, greener, odor-free without additional drying, and more energy-saving.Ink is more fluid, not easy to plug, containing the colloidal composition of the ink has scratch-resistant, waterproof characteristics.

About Us

Shanghai Guanzhong Information Technology was founded in 2007. We are an integrated manufacturer specializing in inkjet technology and Internet of Things RFID reading and writing technology with more than 10 years. In order to our overseas clients easier remember us, we registered the another trade mark "SCORER" in 2013. Now, we have 2 logos to cater to the domestic and foreign markets, "GUANZHONG" & "SCORER".

SCORER is a collection of design, development, production and sales as one. In the field of product digitization, we can protect customer rights and improves end-user experience through technology, innovation, service, and consulting.

Our company has long focused development on spot color and color digital inkjet equipment, high frequency (HF) and ultra high frequency (UHF) reading and writing equipment and software system integration development. We have professional hardware and software R&D team, which can be customized according to the actual production needs of customers Corresponding coding equipment, dedicated to giving each product an exclusive number, provides the prerequisite and foundation for building an interconnected intelligent world.

We uphold the core values of "integrity, altruism, focus", and strive to provide customers with reliable products, high-quality services, and achieve a win-win situation.

Exhibition

Certificate
Pre-sale Service:
1. Inquiry and consulting support2. It can be well worked with SCORER

After-sale Service:
1. Online support. Whenever and wherever you have technical problems, you can contact us at any time, we will do our best to support you to solve the problems.2. The machine will have one year guaranty. During the warranty year if any of the parts broken not by man-made. We will free charge to replace the new one to you. The warranty will begin after the machine send out.

FAQ

1. Why choose SCORER?
-- Our company has dedicated to development, manufacturing and sales of qualified coding machines and consumables for 15 years. Meanwhile, we commit ourselves to satisfy every customer's different needs in coding and marking area.

2. What's the regular lead time for SCORER Products?
-- Lead time for all Dikai good is 1-2 weeks after order confirmation. For the stocked goods, delivery can be made in 2 working days.

3. What's the warranty of SCORER goods?
-- Regularly 12 months after leaving SCORER Warehouse.

4. How about your after-sales service?
-- For the countries where we have distributors, we depend on our distributor to do after sales services. SCORER also provide online technical services besides of continuously upgraded video supports.
